DIY Personal Office Desk Cooler (Peltier)

In stock · Made-to-order resin · Ships from Auckland · Free shipping over $75

Material

High-Detail Resin (8K)

Colour

Grey

Weight

~28 g

Print time

~1.5 h

Shipping

$10 std · $20 express

Lead time

1-3 d print + 1-4 d ship

Stay cool during a hot day! This is DIY small personal office desk cooler. I needed a cooler for my office as my pc is heating the room very fast and I did not wanted to buy a big expensive A/C. My goals for this project were to model everything with the least amount of material waste (support material) needed and that everything is easibly printable. What you need to print: 1x air.stl, 15%-20% infill, support on built plate only (I suggest to set the overhang threshold to 10 or less --> less support) If you have a Prusa MK3 you can print without any support 1x wall, 15% infill, no support 2x holder.stl, 15% infill, no support 1x door_hot.stl, 15% infill, no support 1x door_cold.stl, 15% infill, support on built plate only What you need for the whole project: 1x 140mm fan (I had an old Noctua fan lying around, however any other should do the job as well) (https://www.amazon.com/Premium-Quality-Technology-NF-A14-PWM/dp/B00CP6QLY6) 4x 40x40x20 heatsinks (https://www.banggood.com/40x40x20mm-Aluminum-Heat-Sink-Heatsink-For-CPU-LED-Power-Cooling-p-1146518.html?rmmds=search&cur\_warehouse=CN) 2x 40x40x20 fans (https://www.conrad.ch/de/sunon-eb40201s2-000u-999-axialluefter-12-vdc-1308-mh-l-x-b-x-h-40-x-40-x-20-mm-183786.html?insert=UP&utm\_source=google-shopping-de&utm\_medium=search&utm\_campaign=shopping-online-de&utm\_content=shopping-ad\_cpc&WT.srch=1&gclid=CjwKCAjw8ajcBRBSEiwAsSky\_dYECoYiJZuSFD6bsSRlwpCoavHhqQ9ijatys5uAed4437DHjaVgzhoCNDAQAvD\_BwE) 2x peltier modules (https://www.banggood.com/TEC1-12706-40x40mm-Thermoelectric-Cooler-Peltier-Plate-Module-12V-60W-p-74295.html?utm\_source=google&utm\_medium=cpc\_elc&utm\_campaign=ds-diy-mbz0-rm1&utm\_content=mandy&gclid=CjwKCAjw8ajcBRBSEiwAsSky\_ez-mncAgidBe-f\_q4wIjPXQNfCMaDX4-9y8pC7Sn0kM-ecCospAZRoC0JwQAvD\_BwE) 4x M8 hexagon head bolts 80mm and nuts some 2.9mm brass tubing to mount the doors some little screws to mount the fans on the heatsink some hot glue to fix everything in place a 12V 6-8A PSU I suggest not going higher than 6-8A as the fans will no longer be able to transfer the produced heat. The cooler will no longer cool as the peltiers are getting to hot. If you want you could also 3d print the screws and bolts. I am soon publishing an evaporative cooling approach with much less heat output. UPDATE I improved the doors so now the close completely. Print instructionsCategory: Office Print Settings Printer Brand: Prusa Printer: i3 MK3 Rafts: No Supports: No
